OVER PRESSURE Only if acid circulation is activated. Requires hardware.
The air pressure is above the programmed value in ”Over
pressure”.
Possible causes: Folded air hose.
Measures: Check air hoses.
PHASE ERROR Phase is missing.
Possible causes: Blown mains fuse. Bad connection in
mains plug or terminal blocks. Faulty contactor.
Measures: Check mains fuses. Check connections.
REMOTE MISSING AGV-application.
The value in ”Remote config” is programmed for use of
the remote start input and parking is not permitted.
A battery is connected to the charger and the remote start
signal is not activated.
Possible causes: Bad connection in the remote start input.
The programming of ”remote config” is not according to
the desired function. Faulty proximity switch.
Measures: Check connections and the proximity switch.
Check programming.
TRANSD. ERR T The signal from the temperature sensor in the
transformer or choke is out of range.
Possible causes: Faulty sensor. Faulty pcb.
Measures: Switch the connectors ”temp 1” and ”temp 2”
in connector J7 on the main board. If the error follows
the sensor, replace it. If the error follows the input
channel, replace the main pcb.
TRANSD. ERR Ty The signal from the temperature sensor in the thyristor
cooling fin is out of range.
Possible causes: Faulty sensor. Faulty pcb.
Measures: Switch the connectors ”temp 1” and ”temp 2”
in connector J7 on the main board. If the error follows
the sensor, replace it. If the error follows the input
channel, replace the main pcb.
TRANSD. ERR. IDB Only if IDB-function is activated. Requires hardware.
The IDB-unit reports a temperature out of range.
Possible causes: Faulty battery temperature sensor (short
circuit or bad connection). Faulty IDB-unit.
Measures: Replace the sensor or the IDB-unit.
