MobileCollect Selection Tool
3.2 Mobile Module Connectors
The 3 different types of gage cables used by the Mobile Modules can easily be identified by the
connector at the end of the gage cable that connects to the Mobile Module. The connector for
each of the gage cable types is shown below.
Mini Mobile Module These cables use a 2x3 connector.
Digital Mobile Module These cables use a 2x7 connector.
Command Mobile Module This Mobile Module uses the same cable as the Digital
Mobile Module.
RS-232 Mobile Module These cables use a 2x6 connector.
