2 – Peripheral Signals Assignment Table
The SmartFusion2 architecture provides a very flexible schema for connecting peripherals signals to
either MSIOs or the FPGA fabric. Use the signal assignment configuration table to define what your
peripheral is connected to in your application. This assignment table has the following columns:
MSIO - Identifies the peripheral signal name configured in a given row.
Main Connection - Indicates whether the signal is connected to an MSIO or the FPGA fabric. For the
USB peripheral, the main connection is a function of the mode - ULPI or UTMI - and is not editable.
Direction - Indicates if the signal direction is IN, OUT or INOUT.
Package Pin - Indicates the package pin associated with the MSIO when the signal is connected to an
MSIO.
