Step 2: Device C-cover Keyboard Removal
IMPORTANT: Surface Laptop 3 devices are built with either a fabric type or metal type C-cover keyboard
assembly. The C-cover removal process differs differs between the metal type C-cover and the fabric type
C-cover. Be sure to follow the proper procedure based on the device model and associated C-cover type.
Removal Process (C-cover Keyboard Metal Type)
Preliminary Requirements
IMPORTANT: Be sure to follow all special (bolded) notes of caution within each process section.
Required Tools and Components
· Tools:
o 5IP (Torx-Plus) driver
o Anti-static wrist strap (1M Ohm resistance)
o Recommended: ESD-safe Battery Cover (13.5” or 15”)
· Components:
o New 5IP screw qty=4
o C-cover (If replacing)
Prerequisite Steps:
· Power off device - Ensure device is powered off and disconnected from a power supply.
· General Safety - Check to make sure that general guidelines and ESD compliance steps are followed prior to
opening device. Refer to Prior to Device Disassembly section (page 11) for details.
· Remove feet - Follow steps for Procedure-Removal (Non-Skid Foot Pad) section (page 12) prior to
C-cover removal.
IMPORTANT: Be sure that all foot adhesive remains have been removed from the bottom device case
foot sockets prior to C-cover screw removal to avoid the risk of stripping out the C-cover screw(s).
