5 X22-19688-01
General Information, Precautions, Warnings
This symbol identies important safety and health information in this manual.
Tools Required
Microsoft Recommended Service Jigs:
· Electrostatic Discharge (ESD) safe battery cover (13.5” or 15”)
Standard Service Tools:
· Anti-static wrist strap (1 MOhm resistance)
· Spudger tool
· Torx-plus screwdriver 5IP
· Isopropyl alcohol (IPA), 99%
· Isopropyl alcohol dispense bottle
· Cleaning swabs
· ESD safe tweezers
· Heavy duty suction cups (2) – 2.25”
· Plastic feeler gauge – 0.50mm
· Clamps (2), 2” spring
The tools identied on this list can be purchased from many different commercial sources, including but not limited
to Amazon.com; iFixit; Chemdex, and other vendors.
