Step 3: rSSD Replacement Process
Preliminary Requirements:
CAUTION: Be sure to follow all special (bolded) notes of caution within each process section.
Required Tools and Components
· Tools:
o Torx-plus 5 screwdriver (5IP)
o Anti-static wrist strap (1 MOhm resistance)
o ESD safe battery cover (13.5” or 15”)
· Components:
o New 3IP screw
o rSSD (If replacing)
Prerequisite Steps:
· Power off device - Ensure device is powered off and disconnected from a power supply.
· General Safety - Check to make sure that general guidelines and ESD compliance steps are followed prior to
opening the device. Refer to Prior to Device Disassembly section (page 11) for details.
· Remove feet - Follow steps for Procedure-Removal (Non-Skid Foot Pad) section (page 12) prior to
C-cover removal.
IMPORTANT: Be sure that all foot adhesive remains have been removed from the bottom device case
foot sockets prior to C-cover screw removal to avoid the risk of stripping out the C-cover screw(s).
· Remove C-cover - Follow steps for Device C-cover Keyboard Removal (fabric or metal type) section (page 13).
WARNING: It is recommended that an ESD-safe battery cover of appropriate size (either 13.5” or 15”
device) be placed across the device to protect the battery from any physical contact or accidental
damage whenever C-cover is removed. Ensure corners of cover are aligned with the corners of the device
at all times while battery is exposed. If battery cover is misaligned during activities in any way, re-align
before continuing activities.
