SSD Removal and Reassembly Procedures
Prior to Device Disassembly:
• Before opening the device, always ensure device is powered off and disconnected from a power supply.
• Always ensure that the work surface is covered with an ESD-safe, soft, non-marring material.
• Work surfaces should be cleaned regularly to ensure debris/abrasive particles are not present.
• Check to make sure that general guidelines and ESD compliance steps are followed prior to opening device.
WARNING: It is recommended that an ESD-safe battery cover be placed across the device to protect the
battery from any physical contact or accidental damage whenever C-cover is removed. Ensure corners
of cover are always aligned with the corners of the device while battery is exposed. If battery cover is
misaligned during activities in any way, re-align before continuing work.
CAUTION: Check C-cover and device enclosure for any loose articles that may be present inadvertently
on the C-cover or within the device enclosure.
IMPORTANT: Ensure battery FPC remains disconnected from the PCBA whenever C-cover is removed
from device for safety purposes. Refer to Procedure-Removal (C-Cover) for further details.
Current Battery Warning
WARNING: Please note that the battery bears the following warning label. Please heed the information
provided on the label.
Battery cannot be easily replaced by user
• Risk of re or burning – contact Microsoft for assistance
• Do not separate or remove battery from backplate cover
• Do not modify battery, its wiring, or connectors
• Do not replace, short circuit, bend, crush, or puncture battery
• Do not dispose of battery in re or expose to high temperatures (+140ºF/60ºC)
• For more information: http://aka.ms/surface-security
