Connecting to a USB hub (using with other USB devices):
Connect the USB hub (purchased separately) to your computer's USB port.
NOTE: Use only with a powered USB hub or the optional Microtech Power Adapter may
be required.
Then connect the USB connector of the USB CameraMate to a port on the USB
hub. Make sure the connectors are secured firmly. The USB cable may be plugged
into the computer or hub while the computer is running.
IMPORTANT: Make sure the cable ends are firmly connected. Be careful not to
confuse the upper and lower parts of the connector. Do not force connections, as this
may damage the computer or the USB CameraMate.
Attach the USB connector from the USB hub
to the USB port on your computer
Enlarged view
Attach the USB connector from
the USB CameraMate to the USB
port on the USB hub
Enlarged view
1.
2.
