Microtek TMA 1600 User Manual

8 Microtek TMA1600 Installing and Getting Started
A. Using the 35mm Slide Template
The 35mm Slide Template can hold up to four mounted slides at a time. During
operation, it is recommended that the template be placed on the glass surface first,
and the slides loaded into the template next.
1. Place the template (which the side reads “Microtek” logo should face up) on the
scanner glass surface.
2
1
0
3
4
5
6
6
5
4
3
2
1
Make sure that the template's
front corners are firmly
aligned against the top ruler
of the scanner, and that the
top edges (left and right) fit
within the scanner glass area.
2. Load the film face down inside the frame of template.
2
1
0
3
4
5
6
6
5
4
3
2
1
Align the slide against
the bottom-left corner
of the frame
