Microzone MC8RE-V2 - Functional Diagram and Connections; Technical Specifications

FUNCTIONAL PARSING
DIGITAL PROPORTIONAL R/CSYSTEM
www.microzone.cn
2.4GHz
FHSS
SPECIFICATION PARAMETERS
1 external voltage input
External
voltage
input
(S)signal
(+)positive
electrode
(-)negative
electrode
Contact frequency alignment
After the receiver is powered
on, press the touch button to
turn on the power switch of
the remote control, and the
frequency matching is
successful
7 PWM signal
External antenna
(-)negative
electrode
1 SBUS signal
Frequency range
Receiver supply voltage
SBUS signal
Frequency pairing mode
Recovery performance
Control range
Antenna type
Antenna length
Runaway protection settings
Applications
Weight
Size
Color
Model
Channel output
Remote control support
Voltage return
MC8RE-V2
Teal transparent
7 PWM signals,1 SBUS signals,1 external voltage input
2401MHz-2478MHz
DC:4.5-6V
Fast signal recovery
Contact to frequency
>1000m
150mm
External dual antenna
10g
46*25*1（4 mm）
Fixed wing/Multi-axis/Car/Boat
Support
C7-MINI/8B-MINI/Classic-10
Support
Support
