PART 9 EXPLODED VIEWS AND PARTS LIST
Important Note:
When needing a replacement part, please advise machine Model No. & Part No.
BT1 BT3 BT6 P Air Motor Assembly
Part No.: AMA136
No.$
Part$No.$
Description$
Qty$
No.$
Part$No.$
Description$
Qty$
1"
AMA13601"
Housing"
1"
11"
AMA13611"
Exhaust"cover"
1"
2"
AMA13602"
Deep"groove"ball"bearing"
1"
12"
AMA13612"
Motor"rear"cover"
1"
3"
AMA13603"
Rotor"front"cover"
1"
13"
AMA13613"
Pin"
1"
4"
AMA13604"
Eccentric"stator"
1"
14"
AMA13614"
Cylinder"spring"
1"
5"
AMA13605"
Motor"rotor"
1"
15"
AMA13615"
Rotation"Switch"
1"
6"
AMA13606"
Blade"
5"
16"
AMA13616"
Valve"element"
1"
7"
AMA13607"
Rotor"rear"cover"
1"
17"
AMA13617"
Taper"spring"
1"
8"
AMA13608"
Deep"groove"ball"bearing"
1"
18"
AMA13618"
Nut"
1"
9"
AMA13609"
O"ring"
2"
19"
AMA13619"
Quick"coupling"
1"
10"
AMA13610"
O"ring"
1"
"
"
"
"
