MID BT Series - Part 3 Machine Specifications

6
PART 3 MACHINE SPECIFICATIONS
Drive option: Air, Electric
Air requirement: 900-1500L Per minute @ 0.6/0.7Mpa
Electric requirement:120V60HZ
MODEL
BT1 BT3 BT6 BT8 BT14
Machine Performance Ranges
Working range inside
diameter to outside diameter
16-33.4mm 25-88.9mm 60-168.2mm 65-219.0mm 145-355.6mm
0.62-1.3'' 1-3.5'' 2.3-6.5'' 2.5-8.6'' 5.7-14''
Wall Thickness
≤8mm ≤15mm ≤20mm ≤20mm ≤20mm
≤0.3" ≤0.6" ≤0.78" ≤0.78" ≤0.78"
Rotation speed pneumatic
0-66RPM 0-66RPM 0-61RPM 0-50RPM 0-18RPM
Pneumatic motor
Recommended air pressure
90PSI 90PSI 90PSI 90PSI 90PSI
6.2BAR 6.2BAR 6.2BAR 6.2BAR 6.2BAR
Recommended volume
30CFM 30CFM 30CFM 41CFM 41CFM
0.9m3/Min 0.9m3/Min 0.9m3/Min 1.2m3/Min 1.2m3/Min
Electric motor
Electric motor
BOSH, 1.38HP(1.05kw), 60HZ,120V
1.6HP(1.2kw)
60HZ
2HP(1.5kw) 60HZ
Measure
Machine weight
Pneumatic, Complete
machine
15.4lbs 18.7lbs 35.2lbs 57.2lbs 101.2lbs
7kgs 8.5kgs 16kgs 26kg 46kgs
Electric, Complete machine
17.6lbs 19.8lbs 37.4lbs 61.6lbs 105.6lbs
8kgs 9kgs 17kgs 28kg 48kg
Shipping weight
Pneumatic
14kg(30.8lbs) 15kgs(33lbs) 29kgs(63.8lbs) 41kg(90.2lbs) 68kgs(149.6lbs)
Electric
16kg(35.2lbs) 16kgs(35.2lbs) 31kgs(68.2lbs) 44kg(96.8lbs) 70kgs(154lbs)
Dimensions
Length (L x W x H)
21*16*6.7" 21*16*6.7" 22*21.6*10" 22*11*10" 32.6*17*16"
540*410*170mm 540*410*170mm 560*550*250mm
speed electric
Rotational Drive System
0-65RPM
0-65RPM
0-65RPM
650*
280*250mm 830*430*410mm
0-24RPM
Rotation
0-20RPM
