SOLO mode
To help with identi cation, DP48 will automatically solo the audio for speci c functions and under speci c conditions,
such as the following:
ASSIGN—While assigning input channels to a Group, the selected input channel will be soloed for easy
identi cation. When you exit ASSIGN, the channel solo will be deactivated automatically.
EDIT—While editing the Group mix of the assigned input channels, the selected Group will be
soloed automatically. When you exit EDIT, the Group solo will be deactivated automatically.
Group Processing —If you wish to listen to a Group in solo, e.g., to adjust that Group’s processing, just press
and hold the respective GROUPS 1-12, MIC or AUX IN buttons. That button’s LED will begin ashing, and the Group
display will show a
yellow “S” above the group number.
Solo Mode will also behave in the following ways:
When you switch to a di erent Group or select the MIC or AUX IN buttons while in Solo Mode, the solo will follow
your selection to the newly-selected Group or input.
When you de-select the soloed Group or press any other button, such as MIX A/MIX B or SETUP, the solo is switched
o automatically.
You can also press and hold the soloed Group button again to switch o the solo.
Speci cations
Connections
Phones Mix A / B2 x ¼ " TRS, stereo, unbalanced, 25 Ω
Line Mix A / B2 x ¼ " TRS, mono, balanced, 1 kΩ
2 x ¼ " TRS, mono, unbalanced, 500 Ω
Aux in 2 x ¼ " TRS, unbalanced, 20 kΩ
2 x ¼ " TRS,
balanced, 40 kΩ
AES50 Thru / In2 x RJ45
Equalizer
Low ±15 dB, semi-parametric, low shelving
Mid ±15 dB, semi-parametric, peak
High ±15 dB, semi-parametric, high shelving
Frequency 20 Hz to 22 kHz, adjustable
Output
Limiter Ratio ∞:1
Level, max. +12.8 dBu (Phones)
Mix A / Mix B2 x stereo
AES50
Audio channels @ 48 kHz48
Sample rate 44.1 / 48 kHz
Sample word length 24 bit
Clock synchronization AES50 IN
Latency min. 70 μs per node (AES50)
Cable Ethernet CAT 5e
Cable length max. 100 m
Data / Rec
SD/SDHC format FAT32
Card memory Up to 32 GB supported
Power Supply
AES50 input PoE (IEEE802.3af)
Power consumption max. 14 W (with DC adaptor)
Mains connection External power supply 24 VDC / 600 mA (included)
Dimensions / Weight
Dimensions (H x W x D) 69 x 242 x 164 mm (2.72 x 9.53 x 6.46")
Weight 1.3 kg (2.9 lbs)
24 25Quick Start GuideDP48
