mute
ST
MONO
l
l
r
r
C
18
15
12
9
6
3
0
3
6
9
25
MIDAS HS0004
The left and right PAN controls are used
to place the input channel signals within
a stereo group or stereo master mix. As
well as image placement, the controls
can also adjust the image width from
stereo through mono to reverse stereo
(left and right crossed over). The controls
have a constant power law i.e. -3dB at
the centre position.
The ST switch connects the post fader
channel signals to the stereo master bus
via the pan controls.
The MONO switch connects the post
fader channel signals to the mono master
bus.
The MUTE switch mutes the input
channel at all points after the insert send.
The switch can be controlled from
snapshot automation and by automute
scenes.
The METERS monitor the pre fader peak
signal levels of input channel.
12
