Heritage 3000 Frame Measurements
7.76”
197mm
41.5”
1054mm
14.29”
363mm
51
Configuration data
24 channel 20 mono/4 stereo 140kg 308.6lbs 1054mm x 1441mm 41.49” x 59.73”
32 channel 28 mono/4 stereo 165kg 363.8lbs 1054mm x 1713mm 41.49” x 67.44”
40 channel 36 mono/4 stereo 188kg 414.5lbs 1054mm x 1985mm 41.49” x 78.15”
48 channel 44 mono/4 stereo 215kg 473.9lbs 1054mm x 2257mm 41.49” x 88.86”
56 channel 52 mono/4 stereo 253kg 564.4lbs 1054mm x 2529mm 41.49” x 99.57”
64 channel 60 mono/4 stereo 260kg 573.2lbs 1054mm x 2772mm 41.49” x 109.1”
16 extender user specified 80kg 176.4lbs 1054mm x 657mm 41.49” x 25.88”
These weights are approximate and taken out of flight case.
Also available as a bob-tail.
