Midas HERITAGE 3000 User Manual

vca
9
9
10
10
0 0
+6 +6
0 0
+6 +6
0 0
+6 +6
0 0
+6 +6
0 0
+6 +6
0 0
+6 +6
0 0
+6 +6
0 0
+6 +6
11
22
33
4
5
6
7
8
4
5
6
7
8
fader
fader
insert
insert
PRE PRE
PRE PRE
matrix
The matrix MIX controls (1 to 8) give
continuous adjustment of the sub group
levels sent to the matrix mixes from
+ 6dB to off.
The PRE fader switches change the
signals sent to the matrix mixes from post
group fader to pre group fader.
The PRE insert switches change the
signals sent to the matrix mixes from
post group insert to pre group insert and
override the pre fader switches. It is
important to note that pre insert matrix
sends are also pre the group mutes.
The VCA switches assign the audio sub
groups to VCA control from VCA
masters 9 and 10.
17
