Input/Output Characteristics
Frequency Response @ 48 kHz Sample Rate, 0 dB to -1 dB 10 Hz – 22 kHz
Dynamic Range, Analogue In to Analogue Out (Typical) 106 dB
A/D Dynamic Range, Preampli er and Converter (Typical) 109 dB
D/A Dynamic Range, Converter and Output (Typical) 109 dB
Crosstalk Rejection @ 1 kHz, Adjacent Channels 100 dB
Output level, XLR Connectors (Nominal / Maximum) +4 dBu / +21 dBu
Output Impedance, XLR Connectors (Unbalanced / Balanced) 50 Ω / 50 Ω
Input impedance, TRS Connectors (Unbalanced / Balanced) 20 kΩ / 40 kΩ
Non-Clip Maximum Input Level, TRS Connectors +21 dBu
Output Level, TRS (Nominal / Maximum) +4 dBu / +21 dBu
Output Impedance, TRS (Unbalanced / Balanced) 50 Ω / 50 Ω
Phones Output Impedance / Maximum output Level 40 Ω / +21 dBu (Stereo)
Residual Noise Level, Out 1-16 XLR Connectors, Unity gain -85 dBu 22Hz-22kHz unweighted
Residual Noise Level, Out 1-16 XLR Connectors, Muted -88 dBu 22Hz-22kHz unweighted
Residual Noise Level, TRS and Monitor out XLR Connectors -83 dBu 22Hz-22kHz unweighted
Display
Main Screen 7" TFT LCD, 800 x 480 Resolution, 262k Colours
Channel LCD Screen 128 x 64 LCD with RGB Colour Backlight
Main Meter 24 Segment (-57 dB to Clip)
Power
Switch-Mode Power Supply Auto-Ranging 100-240 VAC (50/60 Hz)
Power Consumption 120 W
Physical
Standard Operating Temperature Range 5°C – 40°C (41°F – 104°F)
Dimensions 890.9 x 607.0 x 256.0 mm (35.1 x 23.9 x 10.1")
Weight 24.5 kg (53.9 lbs)
