Specifi cations
Processing
Input Processing Channels 32 Input Channels, 8 Aux Channels, 8 FX Return Channels
Output Processing Channels 16 aux buses, 6 matrices, main LRC
Internal E ects Engines (True Stereo / Mono) 8 / 16
Internal Show Automation (Structured Cues / Snippets) 500 / 100
Internal Total Recall Scenes (incl. Preampli ers and Faders) 100
Signal Processing 40-Bit Floating Point
A/D Conversion Dynamic Range 24-Bit, 114 dB (8-channel, 192 kHz ready)
D/A Conversion (stereo, 192 kHz ready) 24-Bit, 120 dB Dynamic Range
Connectors
MIDAS PRO Series Microphone Preampli er (XLR) 32
Talkback Microphone Input (XLR) 1
RCA Inputs/Outputs 2/2
XLR outputs 8
Monitoring Outputs (XLR / ¼ " TRS Balanced) 2/2
Aux Inputs/Outputs (¼" TRS Balanced) 6/6
Phones Output (¼" TRS) 2 (stereo)
Digital AES/EBU Output, XLR 1
AES50 Ports (KLARK TEKNIK SuperMAC) 2
Expansion Card Interface 32 Channel Audio Input / Output
ULTRANET P-16 Connector (No Power Supplied) 1
MIDI Inputs / Outputs 1/1
USB Type A (Audio and Data Import / Export) 1
Mic Input Characteristics (Mic input to analogue output)
Design MIDAS PRO Series
THD+N (0 dB gain, 0 dBu output) < 0.01% unweighted
THD+N (+40 dB gain, 0 dBu to +20 dBu output) < 0.03% unweighted
Input Impedance (Unbalanced / Balanced) 10 kΩ / 10 kΩ
Non-Clip Maximum Input Level +23 dBu
Phantom Power (Switchable per Input) +48 V
Equivalent Input Noise @ +45dB gain (150 Ω source) -125 dBu 22Hz-22kHz unweighted
CMRR @ Unity Gain (Typical) > 60 dB
