Midas M32C User Manual

14 M32C DIGITAL RACK MIXER User Manual 15 M32C DIGITAL RACK MIXER User Manual
3. Select Knob Functions
The SELECT knob serves several functions on the M32C. The following table describes the SELECT knob behavior in each of the available scenarios.
Action
Functional Description
Scene Select Mode (Hold the SELECT knob depressed for 2 seconds)
Display >“Scene” in bold
>Current scene number
>Next scene number and name (small) to be loaded on GO
Short press Recalls the selected Scene from M32C internal memory “GO”
> behavior depends on Scene settings/preferences (remote controlled via
editing software)
> Scene safes can only be set/reset remotely
> Scenes/Shows from USB drives can only be accessed remotely
>A complete show can be loaded from an attached USB drive into the internal
memory using Setup Mode
Rotate Preselects the next Scene
Setup Mode (Press SELECT knob to access menu)
Rotate and press Select and enter the Setup pages:
1. Load Show
2. Contrast
3. LEDs
4. Clock Rate
5. Sync
6. IP Address
7. IP (Subnet) Mask
8. IP Gateway
9. Lock
1. Load Show Load show from root directory of attached USB drive
>display 3 rows:
-Load Show
-Exit
-Show Files
>Exit leads back to Setup Mode root level
>Turn clockwise to scroll through a list of show  les found in USB root directory,
push to load selected show and return to Setup Mode root level
2. Contrast LCD contrast
> Rotate to adjust 0-100
> Press to con rm and exit
3. LEDs LED brightness
> Rotate to adjust 0-100
> Press to con rm and exit
4. Clock Rate Select the internal Sample Clock Rate
> Rotate to adjust 44.1 or 48 kHz (change requires to reboot the M32C)
> Press to con rm and exit
5. Sync Choose Clock Synchronisation source
> Rotate to select INT (internal), AES50 (Port) A, or AES50 (Port) B
> Press to con rm and exit
6. IP Address Select the IP Address for M32C
> Rotate to adjust the  r s t triplet (0-255)
> Press to con rm
> Rotate to adjust the second triplet (0-255)
> Press to con rm
> Rotate to adjust the third triplet (0-255)
> Press to con rm
> Rotate to adjust the fourth triplet (0-255)
> Press to con rm and exit
Action
Functional Description
7. IP Mask Select the IP Subnet Mask for M32C
> Rotate to adjust the  r s t triplet (0-255)
> Press to con rm
> Rotate to adjust the second triplet (0-255)
> Press to con rm
> Rotate to adjust the third triplet (0-255)
> Press to con rm
> Rotate to adjust the fourth triplet (0-255)
> Press to con rm and exit
8. IP Gateway Select the IP Gateway for M32C
> Rotate to adjust the  r s t triplet (0-255)
> Press to con rm
> Rotate to adjust the second triplet (0-255)
> Press to con rm
> Rotate to adjust the third triplet (0-255)
> Press to con rm
> Rotate to adjust the fourth triplet (0-255)
> Press to con rm and exit
9. Lock Locks the M32C
>Display “Lock Cancel”
>Press to cancel locking
> Rotating clockwise turns the display from Green to Red backlight and
shows “LOCKED”
>Press and hold the SELECT knob for 5 seconds in order to exit Locked mode

Midas M32C Specifications

General

Channels	40
Buses	25
Matrix Mixes	6
Effects	8 Stereo FX Engines
Type	Digital Mixer
A/D Resolution	24-bit
Bit Depth	24-bit
Motorized Faders	No
USB Audio Interface	Yes
Ethernet Port	Yes
MIDI I/O	Yes
AES/EBU I/O	Yes
Word Clock I/O	Yes
Connectivity	Ethernet, USB, MIDI
Remote Control	Yes, via Ethernet or USB
Inputs - Mic Preamps	16
Outputs - Main	8
Outputs - Other	16 XLR Outputs
EQ Bands	6-band parametric
Data I/O	AES50, Ultranet
Computer Connectivity	USB
Faders	No physical faders
