The SOLO switch sends the in-
put channel signal to the PFL /
mono-and AFL / stereo busses.
If the switch is engaged, the
mon1/2 meters are automatically
used for solo metering.
The SIGNAL (-16dBu) / PEAK
(+16dBu) display monitors the
peak signal level of the pre fader
input channel.
The FADER gives continuous
adjustment of the input channel
level from + 10dB to off.
The 1-2 switch connects the post
fader channel signal to the group
1-2 busses via the pan control.
The 3-4 switch connects the post
fader channel signal to the group
3-4 busses via the pan control.
The MAS switch connects the
post fader channel signal to the
master stereo bus via the pan con-
trol.
9
