Midas XL200

8.
The 40 input
XL200 has a
total of 122 balanced
jacks for
inserts, (arranged
pairs)
as
follows:
40
input channel
inserts sends
40 input
channel
inserts returns
10 audio
group inserts
sends
10 audio group
inserts
returns
8
matrix
insert sends
8
matrix returns
3
matrix insert
sends
3
matrix insert
returns
9.
The XL200
has a peak
program meters
with 10 LED
segments for
each input and
20 LED
segment meters
for each output.
10.
XL200
configurations
XL200-44
XL200-36
XL200-28
XL200-20
40 mono inputs/2
stereo
inputs/6 blank
modules
32
mono inputs/2
stereo inputs/6
blank modules
24 mono
inputs/2 stereo
inputs/6
blank modules
16
mono inputs/2 stereo
inputs/6
blank modules
XL200-24
compact
XL200-16
compact
XL200-32
extender
XL200-24
extender
XL200-16
extender
24 module positions
only
16
module positions
only
32 mono
or stereo inputs
24 mono or
stereo inputs
16
mono or stereo
inputs
1
1 .
XL200
dimensions and
weights
Dimensions
Width
1986mm (XL200-44)
1736mm (XL200-36)
1486mm
(XL200-28)
1236mm
(XL200-20)
1236mm
(XL200-24
compact)
986mm (XL200- 16
compact)
1236mm (XL200-32
extender)
986mm
(XL200-24
extender)
674mm (XL200- 16
extender)
Depth
1020mm
(all consoles)
Height
375mm
(all consoles)
Nett
weight
Shipping weight
129kg/2851b (XL200-44)
301kg/6651b (XL200-44)
