Midcontinent MD23-342 - Page 7

Manual Number 9019161 Revision C, August 18, 2023 7
Physical Attributes
Weight 0.4 pounds (0.17 kg)
Dimensions
2.43” x 2.43” x 1.0” (HxWxD)
Mating Connectors
26-pin D-Sub and backshell MCIA p/n 9019162-1
Pneumatic fittings MCIA p/n 9019162-2
Mounting
Rear Panel Mount with (4) #6-32 screws;
2.25 inch round bezel
Table 1.4
IMU Performance Limits (-3)
Attitude (-3) Pitch Angle
Pitch Rate
Roll Angle
Roll Rate
No limits (360°)
500° per second max
No Limits (360°)
500° per second max
Table 1.5
Qualifications
Certifications
FAA/EASA TSO-C2d (Type B), C3e, C4c, C6e, C8e, C10c,
C106, C113
b
, C201
(
A4H
4
T3
)
Environmental Qualification RTCA DO-160G (details listed in Section 5.2)
Software Qualification RTCA DO-178C, Design Assurance Level A
Lithium-ion Qualification UL 1642
NVIS Display (-21, -22, -23)
Verified for installations requiring NVIS White compliance
with MIL-STD-3009 and RTCA/DO-275
Table 1.6
Exclusivity Rights
Rights U.S. Patent 11,038,389
