Manual Number 9019161 Revision C, August 18, 2023 32
ENVIRONMENTAL QUALIFICATION STATEMENT
MODEL NUMBER: MD23 Series PART NUMBER: 6420023-( )
DESCRIPTION: 2-inch Custom Function Display
CERTIFICATION: FAA TSO-C2d (Type B), C3e, C4c, C6e, C8e, C10c, C106, C113b, C201
MANUFACTURER: Mid-Continent Instrument Co., Inc.
ADDRESS: 9400 E. 34
th
St. North, Wichita, KS 67226, USA
SPECIFICATION: Test Specification (TS) 723 Test Data Sheet (TDS) 723
STANDARD: RTCA DO-160, Rev G, dated 12/08/10
Temperature and Altitude
4 Category F1
Temperature Variation
5 Category B
Humidity
6 Category B
Operational Shock and Crash Safety
7 Category B, E (5R)
Vibration
8
Category R, Curves C, C1
Explosion
9 Category H
Waterproofness
10 Category W
Fluids
11 Category X
Sand and Dust
12 Category S, D
Fungus
13 Category F (by analysis)
Salt Fog
14 Category X
Magnetic Effect
15 Category Z
Power Input
16 Category Z(XX)
Voltage Spike
17 Category A
Audio Frequency Conducted Susceptibility
18 Category Z
Induced Signal Susceptibility
19 Category ZC
Radio Frequency Susceptibility
20
Category W (conducted)
Emission of Radio Freq Energy
21 Category M
Lightning Induced Transient Susceptibility
22
Category B3 (pin injection)
Lightning Direct Effects
23 Category X
Icing
24 Category X
ESD
25 Category A
Fire, Flammability
26 Category C
REMARKS:
Section 4: Category F1 with improvements as declared by the manufacturer:
Operating Low: -40°C Short-time Operating Low: -40°C Decompression: +8000 feet
Operating High: +70°C Short-time Operating High:+85°C Overpressure: -15,000 feet
Section 13: Category F by analysis.
