123
6)
Remove the screw
s of
front side panel
, and
remove the front si
de panel
(1 screw)
7)
Disconnect the fan moto
r
connectors FAN1(3p
,white)
and FAN2(3p,whi
te) from
DC
motor driv
er board.
8)
Remove the fan mo
tor after
unfastening fix
ing screw
s.
⑧
⑦
⑥
