Midea C01 User Manual

1212
4
. Undo the service plate
box
I.Open the filter
cover,
release the screw on
the
lower panel.
II.Turn the washing
machine back at an angle,
pinch the clasp ,and push
it out.
5
. Undo the door lock
I.Open the door of
washing machine.
II.Take the outer gasket
Take the outer gasket
III.Remove two screws on
the door lock, and take
down the door lock.
IV.Take out the door lock
and draw out the plug.
6
. Undo the front plate
I.Remove the service
plate
box
.
II.Undo five screws in
front plate
III.Put the front plate up to
the clasp of the front plate
away from the loading
holder, and then take off
the front plate.
7.
Undo the lower
counterweight
I.Undo the front plate
II.Remove
four screws pull
out the lower
counterweight.
3 UNPACKING WAYS OF MAIN PARTS

Midea C01 Specifications

General

Brand	Midea
Model	C01
Category	Washer
Language	English
