13
3 UNPACKING WAYS OF MAIN PARTS
1313
8. Undo the gasket
I.Undo
the top cover,
control panel, service
plate box, machine door
and the front plate.
II.Remove
the outer gasket
clamp between the door
seal and the front plate.
III.Loosen
the inner gasket
clamp between the door
seal and the front of the
outer tub.
9. Undo the PCB panel
I.Undo the control panel
II.remove 5 screws
between the control panel
and PCB panel
10
. Undo the detergent box
I.Undo
the top cover and
the control pane
II.Release the hose clamp
and pull out the inlet hose.
III.Release
the hose clamp
and pull out the detergent
box hose, and then take
out the detergent box.
11
. Undo the inlet valve
I.Remove the top cover
II.Undo 2 screws between
cabinet and inlet valve.
III.Release the clamp
fixing
the inlet valve and the
inlet hose, and then pull
out the inlet hose.
IV.Take out the inlet
valve
