DC Series HRV
8
DC Series HRV
Engineering Data Book
ļ‚Ÿ HRV-D1500(B)~HRV-D2000(B)
Return air inlet
Fan
heat exchange core
Air filter
Supply air outlet
Fan
Fresh air inlet
Exhaust air outlet
Electric control box
Sheet metal type air duct
By-pass
Air filter
