Midea Forest MSAFB-12CRN1-NB8

Specifications
 Page 15 
5. Refrigerant Cycle Diagrams
5.1 Cooling only
Capacity(Btu/h).
Pipe Size (Diameter:ø)
mm(inch)
Piping length (m/ft) Elevation (m/ft)
Additional Refrigerant
Gas Liquid Rated Max. Rated Max.
12k 9.52(3/8) 6.35(1/4)
5/16.4
20/65.6 0 8/26.2
15g/m (0.16oz/ft)
18k 12.7(1/2) 6.35(1/4) 25/82 0 10/32.8
24k 15.9(5/8) 9.52(3/8) 25/82 0 10/32.8 30g/m (0.32oz/ft)
