Installation
Page 35
Accessories
Name Shape Quantity
Mounting plate 1
Clip anchor 5~8(depending on models)
Mounting plate fixing screw ST3.9 X 25 5~8(depending on models)
Remote controller
Mode
Timer
TurboI ON
LED
ON/OFF Fan
Follow
me
Self
clean
1
Fixing screw for remote controller holder ST2.9 x
10
2
Optional
Parts
Remote controller holder 1
Dry battery AAA.LR03 2
Seal
1(for cooling & heating
models only)
Drain joint
Owner’s manual&Installation manual
pmifqJqvmb=ol l j=^f o=` l kaf qf l kbo
l ï åÉê∞ë=j ~åì ~ä
l ~ë á ë =mäì ë=p Éêá Éë
^ää =j çÇÉä=kì ã ÄÉêë
1
Remote controller manual
AIR CON DITION ER
REMO TE CONTR OLLE R MANUAL
1
Small Filter(Need to be installed on the
back of main air filter by the authorized
technician while installing the machine)
1~2(depending on models)
Connecting pipe assembly
Liquid side
Φ6.35 (1/4in)
Parts you must purchase.
Consult the dealer about
the pipe size.
Φ9.52 (3/8in)
Gas side
Φ9.52 (3/8in)
Φ12.7 (1/2in)
Φ16 (5/8in)
Φ19 (3/4in)
