Midea HS-625FWEN

Service Manual_2020-V1.0
30
3） Remove 2 screws
4） Pull out the connector terminal and replace the
display control board.
*The temperature control indication sticker is likely to be
damaged when replacing, thus it is advised to prepare
one for standby before replacement
7.9 Main control board
Main control board
1） Remove 2 fitting screws of main control panel
mounting box
2) Take out the mounting box, pry up the cover,
disconnect the wiring terminal.
