NOTE:DO NOT allow water to enter the remote
control.
Use the trap and putty to seal the wires.
Putty
Putty
Putty
Trap
Trap
Trap
Fig. 4
a. For exposed mounting, cut holes on four of the
sides according to Fig. 5.
b.
For shielded wiring, please refer to Fig. 6.
