Midea LRSJ-60/NYN1 User Manual

23
No. Part Name Quantity No. Part Name Quantity
1
Rear net
1 12.9
Wire joint
1
2
Side board
1 12.10
Wire clamp
2
3
Target switch
1 12.11
Wire joint
2
4
Main capillary ass'y
1 13
Handle
2
5
Titanium heat exchanger
1 14
Wire controller
1
6
Hight pressure meter
1 15
Front side board
1
7
right side board
1 16
Front panel
1
8
Base ass'y
1 17
Grille
1
9
Solenoid
1 18
Axial flow fan
1
10
4-way valve ass'y
1 19
Motor
1
10.1
Pressure controller
1 20
Condenser ass'y
1
10.2
4-way valve
1 20.1
Flute shape pipe ass'y
1
10.3
Accumulator tank
1 21
Left bracket
1
11
Compressor
1 22
Rear supporter
1
12
E-part box ass'y
1 23
Motor bracket ass'y
1
12.1
Main controller board ass'y
1 24
Cover
1
12.2
Middle connection board ass'y
1 25
Partition board ass'y
1
12.3
Relay
1 26
Temperature sensor
2
12.4
Motor capacitor
1 27
Temp.sensor ass'y
1
12.5
Transformer
1 28
Discharge temp sensor ass'y
1
12.6
Compressor capacitor
1 29
room temp sensor ass'y
1
12.7
Contactor
1 30
Compressor electric heater
1
12.8
Wire joint
1

Midea LRSJ-60/NYN1 Specifications

General

Brand	Midea
Model	LRSJ-60/NYN1
Category	Water Heater
Language	English
