1. Specifications
HPWH SPECIFICATION
Model CE-LRSJ-60/NYN1 CE-LRSJ-80/NYN1 CE-LRSJ-120/NYN1 CE-LRSJ-140/NYN1
Power supply Ph-V-hz 220-240V 50Hz 1Ph 220-240V50Hz1Ph 220-240V 50Hz 1Ph 220-240V 50Hz 1Ph
Capacity
kW 6 8 12 14
Input
kW 1.15 1.52 2.40 2.55
Water
Heating
Outdoor ambient
temperature
(-7℃～38℃) (-7℃～38℃) (-7℃～38℃) (-7℃～38℃)
Capacity kW 4.0 5.8 8.4 10.35
Input kW 1.25 1.5 2.4 2.9
Water
Cooling
Outdoor ambient
temperature
(15℃～43℃) (15℃～43℃) (15℃～43℃) (15℃～43℃)
COP 5.2 5.3 4.9 5.3
Max power kW 1.45 1.9 3.3 3.5
Outdoor noise level
dB(A) 58 58 58 58
Refrigerant type/Quantity
Kg R410A/1.0 R410A/1.25 R410A/1.6 R410A/1.85
Heat exchanger
material
Titanium-tube
thermal exchanger
Titanium-tube
thermal exchanger
Titanium-tube
thermal exchanger
Titanium-tube
thermal exchanger
Water inlet and
outlet pipe
diameter
mm
DN50 DN50 DN50 DN50
Drain pipe
diameter
mm
DN25 DN25 DN25 DN25
Heat
exchanger
Max. pressure
MPa 0.4 0.4 0.4 0.4
Fin type
Hydrophilic
aluminium
Hydrophilic
aluminium
Hydrophilic
aluminium
Hydrophilic
aluminium
Tube outer type
innergroove tube innergroove tube innergroove tube innergroove tube
Air side
exchanger
Air outflow mode
air flow from rear air flow from rear air flow from rear air flow from rear
Dimension
(W*H*D)
mm
1015*705*385 1015*705*385 1050*855*315 1050*855*315
Packing
(W*H*D) mm 1095*755*455 1095*755*455 1170*905*410 1170*905*410
Outdoor
unit
Net/Gross weight
kg 64/73 66/77 75/85 75/85
Water contented capacity (m3)
40.0 50.0
60～85 75～100
Hot Water Yield
m
3
/h
2.3 2.8 3.8 3.8
Wire controller
KJRH-90B/E KJRH-90B/E KJRH-90B/E KJRH-90B/E
Water Heating Outwater Temp
℃
11℃～35℃ 11℃～35℃ 11℃～35℃ 11℃～35℃
Water Cooling Outwater Temp
℃
6℃～30℃ 6℃～30℃ 6℃～30℃ 6℃～30℃
Compressor current protection
value A
10 12 20 22
Remark:
1. The test conditions: outdoor temp.
Water Heating： outdoor temp. 24/19℃(DB/WB), inlet water temp. 27℃,outlet water temp. 29℃
Water Cooling： outdoor temp. 35/24℃(DB/WB), inlet water temp. 27℃
2. The specification may be changed for product improvement, please refer to the nameplate.
