Specifications
Page 13
Indoor model MSAEAU-09HRFNX-QRD0GW MSAEBU-12HRFNX-QRD0GW MSAECU-18HRFNX-QRD0GW MSAEDU-24HRFNX-QRD0GW
Power supply (Indoor ) V- Ph-Hz 220~240-1-50 220~240-1-50 220~240-1-50 220~240-1-50
Cooling
Capacity Btu/h 9000 12000 18000 25000
Input W 24 24 34 62
Current A 0.11 0.11 0.15 0.28
Heating
Capacity Btu/h 10000 14000 19000 26000
Input W 24 24 34 62
current A 0.11 0.11 0.15 0.28
Indoor fan
motor
Model ZKFP-20-8-6-7 ZKFP-20-8-6-7 ZKFP-30-8-3 ZKFP-58-8-1
Input W 50 50 36 58
Capacitor uF / / / /
Speed(Hi/Mi/Lo) r/min 1100/900/750 1100/900/750 1100/1000/800 1100/1000/800
Indoor coil
a.Number of rows 3.0 2.0 2.0 2.0 2.0
b.Tube pitch(a)x row
pitch(b)
mm 21x13.37 21x13.37 21x13.37 21x13.37
c.Fin spacing mm 1.2 1.2 1.2 1.3
d.Fin type (code) Hydrophilic aluminum Hydrophilic aluminum Hydrophilic aluminum Hydrophilic aluminum
e.Tube outside dia.
and type
mm Φ7,Inner groove tube Φ7,Inner groove tube Φ7,Inner groove tube Φ7,Inner groove tube
f.Coil length x height
x width
mm
598x84x13.37+598x105x26.74
+598x84x26.74
598x84x13.37+598x105x26.74
+598x84x26.74
750x189x26.74+
750x105x26.74
820x189x26.74+
820x126x26.74
g.Number of circuits 2 2 3 5
Indoor air flow (Hi/Mi/Lo) m3/h 549/482/357 549/482/357 809/718/545 978/864/646
Indoor sound pressure level (Hi) dB(A) 39.5/25.5/22.5 41.5/28/23 44.5/28.5/24 45.5/35.5/27
Indoor sound power level (Hi) dB(A) 53 54 57 59
Indoor unit
Dimension(W*D*H) mm 805x193x302 805x193x302 964x222x325 1106x232x342
Packing (W*D*H) mm 875x375x290 875x375x290 1045x405x310 1195x420x320
Net/Gross weight Kg 8.3/11 8.2/10.9 10.8/14.3 14.3/18.2
Design pressure MPa 4.3/1.7 4.3/1.7 4.3/1.7 4.3/1.7
Refrigerant
piping
Liquid side/ Gas side mm(inch) Φ6.35/Φ9.52(1/4"/3/8") Φ6.35/Φ9.52(1/4"/3/8") Φ6.35/Φ9.52(1/4"/3/8") Φ6.35/Φ9.52(1/4"/3/8")
Controller
Wired
Control
Remote Control Remote Control Remote Control Remote Control
Operation temperature °C 17~30 17~30 17~30 17~30
Room tem-
perature
Cooling °C 17~32 17~32 17~32 17~32
Heating °C 0~30 0~30 0~30 0~30
Notes:
1) Capacities are based on the following conditions:
Cooling(T1): - Indoor Temperature 27°C(80.6°F) DB /19 °C(66.2°F) WB Heating: - Indoor Temperature 20°C(68°F) DB / 15°C(59°F) WB
-Outdoor Temperature 35 °C(95°F) DB /24 °C(75.2°F) WB -Outdoor Temperature 7°C(44.6°F) DB / 6°C(42.8°F) WB
-Interconnecting Piping Length 5m - Interconnecting Piping Length 5 m
- Level Difference of Zero. - Level Difference of Zero.
2) Capacities are Net Capacities.
3) Due to our policy of innovation some specifications may be changed without notification.
