Midea MCA3U-09HRFN1-M(C)

280
5) Remove the screws of
the right side panel(5
screws)
2
Fan ass’y
How to remove the fan
ass’y.
1)After remove the panel
plate following procedure 1
2) Remove the nut fixing
the fan, and remove the
fan.
3) Remove the four fixing
screws of the fan motor,
then remove the motor.
