Midea MCCU-7CN2 - Connection Accessory List

R407C MCCU Technical Manual MCAC-UTSM-2012-05
12
7. Connection accessory list
For cooling only units:
Capacity
kW
Sight glass Solenoid valve Solenoid valve coil Drier filter
Thermal
expansion valve
Model Qty. Model Qty. Model Qty. Model Qty. Model Qty.
7 SGN+10s 1
EVR6
1 018F6251 1 DTG63016-33C 1 TGEZ2.5 1
10 SGN+10s 1
EVR6
1 018F6251 1 DTG63016-33C 1 TGEZ2.5 1
14 SGN+12s 1
EVR10
1 018F6251 1 DTG63016-44C 1 TGEZ 3.5 1
16 SGN+10s 1
EVR6
1 018F6251 1 DTG63016-33C 1 TGEZ5 1
22 SGN+12s 1
EVR10
1 018F6251 1 DTG63016-44C 1 TGEZ7 1
28 SGN+12s 1
EVR10
1 018F6251 1 DTG63016-44C 1 TGEZ7 1
35
45 SGN+16s 1
EVR15
1 018F6251 1 DTG63016-55C 1 TGEZ12 1
For cooling and heating units:
Capacity
kW
Sight glass Solenoid valve
Solenoid valve
coil
Drier filter
Thermal expansion
valve
Check valve
Model Qty. Model Qty. Model Qty. Model Qty. Model Qty. Model Qty.
7 SGN+10s 1
EVR6
1 018F6251 1 DMB083S 1 TGEZ2.5 2
DXF-18
2
10 SGN+10s 1
EVR6
1 018F6251 1 DMB083S 1 TGEZ2.5 2
DXF-18
2
14 SGN+12s 1
EVR10
1 018F6251 1 DMB084S 1 TGEZ3.5 2
DXF-06V
2
16 SGN+10s 1
EVR6
1 018F6251 1 DMB083S 1 TGEZ5 2
DXF-18
2
22 SGI+12s 1
EVR10
1 018F6251 1 DMB164S 1 TGEX7.5 2
DXF-06V
2
28 SGI+12s 1
EVR10
1 018F6251 1 DMB164S 1 TGEX7.5 2
DXF-06V
2
35
45 SGN+16s 1
EVR15
1 018F6251 1 DMB165S 1 TGEZ12 2
DXF-02V
2
Note:
Midea CCU can be free connected with other indoor units, such as DX AHU, through a set of connection accessories which are
listed above. Please install these accessories according to the piping diagram and the installation manual of each accessory.
