MCAC-UTSM-2012--05 R407C MCCU Technical Manual
41
No. Part Name QTY BOM Code No. Part Name QTY BOM Code
1 top cover welding part 1 201275990072 12.12
Three-phase power
protection devices
1 202301600518
2 low pressure valve assy’ 1 201675990295 13 front-right support pillar 1 201275990070
2.1 Pipe joint 1 201601200004 14 asynchronism fan motor 2 202400400563
2.2 Valve body 1 201601600314 15 condenser assy’ 1 201575990016
3
Electronic control box
mounting plate
1 201275990060 15.1 condenser 1 201575990007
4
fan motor supproting
assy’
1 201275990073 15.2
condenser input pipe
assy’
1 201675990282
5 The air grille 2 201275990062 15.3 condenser output assy’ 1 201675990281
6 Axial fan 1 201200300014 16 Axial fan 1 201200300035
7 Handle 2 201148700003 17 The partition 1 201275990066
8 After the column about 2 201275990068 18 Left panel 1 201275990064
9 Right front panel 1 201275990063 19 Before the column 1 201275990069
10
Under electronic control
box mounting plate
1 201275990061 20 front-left pillar assy’ 1 201275990095
11 Chassis Parts 1 201275990097 21
Electronic control box
cover
1 201275990065
12 outdoor electric box assy’ 1 203375990017 22 back middle pillar 1 201275990092
12.1 electric box welding assy’ 1 201275990107 23 Wooden chassis 1 202675990010
12.2
wiring base installation
assy’
1 201275990087 24
compressor suction pipe
assy’
1 201675990302
12.3
Outdoor control board
assembly
1 201375990006 24.1 pressure controller 1 202301800953
12.4 Capacitor 2 202300320025 25 Gas-liquid separator 1 201601100097
12.5 Relay 2 202300800071 26 copeland compressor 1 201401400710
12.6 AC contactor 1 202300850050 27 high pressure valve assy’ 1 201675990293
12.7 Transformer 1 202300900093 27.1 Valve body 1 201601600312
12.8 Wire joint 1 202301450110 28
Discharge pipe of
compressor
1 201675990297
12.9 Wire joint 1 202301450121 28.1 Pipe joint 1 201601200004
12.10 Wire joint 7 202301450122 28.2 Pressure controller 1 202301820042
12.11 Wire joint 1 202301450130 - - - -
