MCAC-UTSM-2012--05 R407C MCCU Technical Manual
43
No. Part Name QTY BOM Code No. Part Name QTY BOM Code
1
Welding together pieces
of roof
1 201275990102 13 Front right column 1 201275990109
2
Low-pressure valve
assembly
1 201675990276 14 Induction motor 2 202400400456
2.1 Pipe joint 1 201601200004 15 Condenser components 1 201575990014
2.2 Cube Valve 1 201601601291 15.1 Condenser 1 201575990015
3
Electronic control box
mounting plate
1 201275990060 15.2
Input tube condenser
components
1 201675990258
4 Motor bracket assembly 1 201275990106 15.3
Output tube condenser
components
1 201675990244
5 The air grille 2 201275990062 16 Axial fan 1 201200300035
6 Axial fan 1 201200300014 17 The partition 1 201275990066
7 Handle 2 201148700003 18 Left panel 1 201275990064
8 After the column about 2 201275990068 19 Before the column 1 201275990069
9 Right front panel 1 201275990063 20
Components before the
left column
1 201275990104
10
Under electronic control
box mounting plate
1 201275990061 21
Electronic control box
cover
1 201275990065
11 Chassis Parts 1 201275990097 22 After the column 1 201275990067
12
Outdoor electronic
control box components
1 203375990016 23 Wooden chassis 1 202675990010
12.1
Outdoor control board
assembly
1 201375990006 24
Components of the
compressor back to the
trachea
1 201675990267
12.2 Relay 2 202300800071 24.1 pressure controller 1 202301800953
12.3 Contactor 1 202300850034 25 Gas-liquid separator 1 201601100097
12.4 Transformer 1 202300900093 26
copeland compressor
（ with accessory）
1 201401400720
12.5 Wire joint 1 202301450110 27
High-pressure valve
assembly
1 201675990269
12.6 Wire joint 1 202301450121 27.1 Cube Valve 1 201601600316
12.7 Wire joint 7 202301450122 28
Discharge pipe of
compressor
1 201675990278
12.8 Wire joint 1 202301450130 28.1 Pressure controller 1 202301820042
12.9
Three-phase power
protection devices
1 202301600518 28.2 Pipe joint 1 201601200004
12.10 Compressor capacitor 2 202401000410 - - - -
