MCAC-UTSM-2012--05 R407C MCCU Technical Manual
49
11.10 MCCU-10HN2
No. Part Name QTY BOM Code No. Part Name QTY BOM Code
1 Motor 1 202400440401 13.3 Wire joint 1 202301450117
2 Motor bracket assy’ 1 201275590020 13.4 Wire joint, 5p 1 202301450039
3 Rear net 1 201148700000 13.5 AC contactor 1 202300850046
4 Condenser assy’ 1 201575600020 13.6 Main control board assy’ 1 201347890001
5 Compressor 1 201400710500 13.7 Wire joint,4p 1 202301450003
6 Big handle 1 201148200005 13.8 Transformer 1 202300900551
7 Valve plate 1 201248790001 14 Fixing ring 1 201245000901
8 Suction pipe assy’ 1 201675590094 15 Accumulator cylinder 1 201601000149
8.1 Pressure controller 1 202301820031 16 Base assy’ 1 201248700125
9 4-way valve assy’ 1 201675690013 17 Front right clapboard assy’ 1 201248700056
9.1 4-way valve 1 201600600114 18 Front net assy’ 1 201248700055
9.2 Low pressure valve 1 201600720414 19 Front panel 1 201248700052
9.3 Solenoid 1 201600600045 20 Net clamp 10 201135110801
10 Branch pipe assy’ 1 201647010225 21 Axial flow fan 1 201195000001
11 Discharge pipe assy’ 1 201675590438 22 Rear right clapboard assy’ 1 201248700053
11.1 Pressure controller 1 202301820025 23 Partition board assy’ 1 201248700006
12 High pressure valve assy’ 1 201675590089 24 Left holder 1 201248700050
12.1 High pressure valve 1 201600740619 25 Rear Supporter 1 201245420620
12.2 Strainer 1 201600900023 26 Top cover assy’ 1 201248700051
12.3 One way valve 1 201600800029 27 Discharge temp sensor 1 202301610024
12.4 Strainer 1 201600900075 28 Temp.sensor assy’ 1 202440500002
13 E-part box assy’ 1 203347890001 29 Compressor electric heater 1 202447090021
13.1 Capacitor 1 202300320025 30 Room temp sensor assy’ 1 202301300196
13.2 Electric installation board 1 201275590077 - - - -
