MCAC-UTSM-2012--05 R407C MCCU Technical Manual
51
11.12 MCCU-16HN2
No. Part Name QTY BOM Code No. Part Name QTY BOM Code
1 Condenser assy’ 1 201575890058 19.1 Low pressure valve 1 201600720098
2 Motor bracket assy’ 1 201275600085 20 Discharge pipe assy’ 1 201675890379
3.1 Motor 1 202400400185 20.1 Branch pipe 1 201600500210
3.2 Motor 1 202400400186 20.2 Pressure controller 1 202301820025
4 Front panel 1 201275600092 20.3 Muffler 1 201601000041
5 Axial flow fan 2 201100300102 21 Handle 2 201148700009
6 Front net assy’ 2 201275890056 22 E-part box assy’ 1 203375890098
7 Front-right panel assy’ 1 201275890054 22.1 Electric installation board 1 201275600094
8 Valve plate 1 201248790001 22.2 Wire joint,4p 1 202301450003
9 Rear-right panel 1 201275600089 22.3 Wire joint 3 202301450117
10 Separator 1 201601100066 22.4 AC contactor 1 202300850045
11 Partition board assy’ 1 201275890038 22.5 Transformer 1 202300900551
12 Compressor 1 201400710460 22.6 Motor capacitor 2 202401100407
13 Base 1 201275600095 22.7 Main control board assy’ 1 201347890001
14 Rear supporter 1 201275600086 22.8 Wire joint, 5p 1 202301450039
15 Top cover 1 201275600087 23 Discharge temp sensor 1 202301610500
16 Rear-left supporting board 1 201275600088 24 Room temp sensor assy’ 1 202301300196
17 4-way valve assy’ 1 201675890410 25 Temp sensor assy’ 1 202450200331
17.1 4-way valve 1 201600600009 26 Compressor electric heater 1 202495020901
17.2 Low pressure valve 1 201600720414 27 Compressor wire joint assy’ 1 202445400405
18 Suction pipe assy’ 1 201675890408 28 Drainage cover 1 201148790000
18.1 Pressure controller 1 202301820026 29 Big handle 1 201157390002
19 High pressure valve assy’ 1 201675890381 - - - -
