MCAC-UTSM-2012--05 R407C MCCU Technical Manual
53
1 Rear left vertical supporter 1 201295590027 18 High pressure valve 1 202301820005
2 Front right vertical supporter 1 201295590030 19 High temp. switch 1 202301820008
3 Rear right vertical supporter 1 201295590028 20 Low pressure valve assy’ 1 201657600010
4 Side cover panel 2 201295590012 20.1 Low pressure valve 1 201600710100
5 Top cover 1 201195590002 20.2 Filter 1 201600910108
6 Rear cover 1 201295590013 21 High pressure valve assy’ 1 201657600015
7 Motor 1 202400400031 22 Seal plate of condenser 2 201295590026
8 Axial fan 1 201100300203 23 Front cover 1 201295590054
9 Fan supporter 2 201295590017 24 Valve fixing board 1 201257600004
10 Fixing board of E-box 1 201295590025 25 Coil of low pressure valve 2 201295000016
11 Upper fixing board of E-box 1 201295590024 26 Basement of compressor 2 201257600001
12 Grille 2 201295590009 27 Basement 1 201257600003
13 E-box 1 203357600000 28 Gas- liquid seperator 1 201601100045
13.1 PCB assy’ 1 201395020640 29 Condenser 1 201557600003
13.2 Transformer 1 202300900551 30 Compressor 1 201401430110
13.3 Contactor 1 202300850050 31 Left fixing board of fan 1 201295590018
13.4 Capacitor of compressor 1 202401000410 32 Left supporter 1 201295590029
13.5 Installing panel 1 201295500187 33 Top front cover 1 201295590053
13.6 E-box cabinet 1 201295500188 34 Guide net of fan 1 201295590043
14 Grille 1 201295590010 35 High pressure valve assy’ 1 201657600029
15 Suction pipe 1 201657600026 35.1 High pressure valve 1 201600710512
16 4-way valve assy’ 1 201657600019 35.2 Filter 1 201600900055
16.1 4-way valve 1 201600620004 36 Rubber pad 2 202790150330
16.2 Coil of 4-way valve 1 201600600113 37 Solenoid valve 1 201657600012
17 Muffle 1 201601000046 - - - -
