Midea MCCU-7CN2 - Page 57

MCAC-UTSM-2012--05 R407C MCCU Technical Manual
57
1 Rear net 2 201295100172 22
Front-right supporting
board
1 201295100163
2 Top cover 2 201195100000 23 Separator 1 201601100036
3 Axial flow fan 2 201100300205 24 Net 1 201295100157
5 Cover board 2 201295100149 25 Motor bracket assy’ 1 201295100171
6 Middle supporting assy’ 2 201295100167 26 Baffle assy’ 1 201295030810
7 Wind baffle assy’ 1 201295030814 27 Below condenser assy’ 1 201575990001
8 E-part box assy’ 1 203375990000 28 E-part box Support board 1 201295000076
8.1 Main control board assy’ 1 201375990000 29 Up condenser assy’ 1 201575990000
8.2 Current detecting board assy’ 1 201390000827 30 Motor bracket assy’ 1 201295100168
8.3 Middle connection board assy’ 1 201390500120 31 Motor bracket assy’ 1 201295100169
8.4 Relay 2 202300800071 32 Support board 2 201295030841
8.5 Contactor 3 202300850043 33 Rear clapboard assy’ 1 201295030812
8.6 Transformer 1 202300900093 34 Rear-right supporting board 1 201295100165
8.7 Transformer 1 202300900550 35 Support board 1 201295100158
8.8 Compressor capacitor 2 202401000303 36 Rear-left supporting board 1 201295100164
8.9 Surge suppresser 3 202301610601 37 Cover supporter 1 201295030829
9 Net 1 201295100156 38 Cover supporter 1 201295030828
10 E-Part box cover 1 201295500179 39 Motor 2 202400420231
11 E-part box Support board 1 201295000011 40 Compressor 3 201400410920
12 Valve plate 1 201295100150 41
Compressor supporter
assy’
1 201275990053
13 Ball valve supporter assy’ 1 201295100161 42
Compressor supporter
assy’
1 201275990054
14 Discharge pipe assy’ 1 201675990035 43
Compressor supporter
assy’
2 201275990055
14.1 Pressure controller 1 202301820005 44 Capillary assy’ 1 201675990006
15 4-way valve assy’ 1 201675990014 45 Oil separator 1 201601100031
15.1 4-way valve 1 201600600065 46 High pressure valve 1 201695030820
15.2 4-Ways valve solenoid 1 201600600103 46.1 Low pressure valve 1 201600770304
16 Cover plate 2 201295100159 47 Suction pipe assy’ 1 201675990008
17 Base 1 201295100176 47.1 Pressure controller 1 202301820008
18 Front-left supporting board 1 201295100162 48 Low pressure valve assy’ 1 201675990004
19 Front-left clapboard 1 201295100151 48.1 Ball valve 1 201600810006
20 Mid-front holder 1 201295100166 49
High pressure valve
connecting pipe assy’
1 201675990000
21 Front-right board 1 201295100170 - - - -
