MCAC-UTSM-2012--05 R407C MCCU Technical Manual
7
4.3 MCCU-16CN2
4.4 MCCU-22CN2,MCCU-28CN2, MCCU-35CN2
Sight glass
TXV
Filter drier
Solenoid valve
Connection accessories
Cooling
Compressor
Indoor unit
Discharge temp. sensor
HP Switch
Liquid-gas seperator
Outdoor heat-exchanger
Stop valve Stop valve
LP Switch
T3
Sight glass
TXV
Filter drier
Solenoid valve
Connection accessories
Discharge temp. sensor
HP Switch
Liquid-gas seperator
Outdoor heat-exchanger
Stop valve Stop valve
LP Switch
T3
Cooling
Compressor
Indoor unit
