5.3 Notice.
1.When you Remove the cabinet motherboard, pay attention to wear Gloves in case hurting your hands;
2.Do not rub the Cabinet in order not to influence its nicety;
3.Pay attention to take all the screws and stuff trimly;
4.When you install all the screws, make sure all the screws firmly and not ineffectively.
5.DISASSEMBLY INFORMATION FOR THE PRODUCT
- 18 -
8-8. Remove the motor bracket, Bottom plate and the air
duct
P1(white) Temperature sensor
P2(brown) Door switch
P3(purple) Motor
P4(blue) Power cord
P5(metal) Heating pipe
P6(metal) Heating pipe
