ITEM PICTURE
Pull out the cycle select knob
.
Remove 2 screws between the
control panel and the PCB housing.
and unplug the
terminal
Remove
control panel.Then
u
nscrew 3 screws on the plastic
cover and take away.
Unscrew 5 screws on the
control
panel.
Take off the planstic line and then
remove 2 screws between the
control panel and side plate
Open the box and pull out all
connection pins behind the Control
panel sub.
3 Disassembling Ways of Main Parts
