6
2UnpackingWaysOfMainParts
Stepsofdisassemblingmachine Pictures
1.Removethetopcovercomponentsofthecase
(1)Removethescrewcap;
(2)Removethescrewsfixedroofcomponent;
(3)Takeouttheroofcomponent.
2.Removethebackboardcomponentofthecase
(1)removethescrewsfixedbackboard;
(2)removethescrewsfixedthermostatsupport
component;
(3)pulledoutwireharnessassemblyandLinefirmand
terminalconnectedwithbackboard;
(4)takedownthebackboardcomponent.
2‐1.Removedthebackventflange
2‐2.Removethepowerline
