Stepsofdisassemblingmachine Pictures
2‐3.Removethefilter
3.removethedoorcomponent(includingthedoor
hinge)
(1)removethescrewsfixeddoorhinge;
(2)takedownthedoorcomponentandhinge.
3‐1.removethedoorhinge,frontdoorandback
doorframe
4.Removetheinnertubassey
(1)Removethe
reinforcedplate;
(2)takeoutthebeltfromthemotorshaft;
(3)removedthescrewswhichisfixeddrumkitand
the
automaticthermostat;
(4)pullouttheterminalconnectedwirewithheating
pipe;
(5)takeoutthedrumkitandthebelt.
4‐1.Removethebodyofdrum,liftingbar,heating
pipe
cover
anddrumshaft,etc
4‐2.Removetheheatingpipe,heatingpipecover
andits
Support
2UnpackingWaysOfMainParts
