Stepsofdisassemblingmachine Pictures
5.Removethecontrolpanelcomponent
(1)removedthescrewsfixedcontrolpanelcomponent;
(2)Pullout theterminalsconnectedwirewithPCBboard.
5‐1.Removethecontrolpannel,PCBboardandbuttons,
etc.
6.Removethewiringharness(includingthethermostat)
(1)removeallthelinefirmfixed
wires;
(2)pullouttheterminalsconnectedthewireswiththe
motorandthedoorswitch;
(3)takeoutthewires.
6‐1.Removetheautomaticthermostat
6‐2.Removethesupportcomponentsofthemanual
Thermostat
6‐3.Removethemanualthermostat
