4. Service Spaces
Please avoid installing in the following places:
A place with flammable gas or material.
A saline place such as a seashore vicinity.
A place with sulphur gas.
A place with oil gas, such as kitchen.
A place with high-humidity air.
An unbearable place.
A place where high-frequency waves are generated.
The appliance shall not be installed in the laundry.
Please comply with the related national electric standard to make electric insulation for construction and metal
parts of air-conditioner.
Please choose the place where the ventilation is good.
Ceiling space requires ≥Cm.
The installation height of the unit can not be higher than D mm, or it will affect the operation effect.
Unit：mm
Unit：mm
≥ 1 0 0
A
≥ 1 0
0
≥B
E ≥ 1 0 0
Air return port
Fan angle range
18-36 45-71
A
1180
B
1380
C
153
D
3200
E
465
1350
1550
189
4000
505
