Table 3.5: Address determination procedure examples
Example
no.
Alarm state
LED states
Address
range
Address range
base value
Sum of LED
contributions
Unit address
1
Not sounding
OPERATION
On
0 - 15
0
14
(= 8 + 4 + 2)
14
(= 0 + 14)
TIMER
On
DEF./FAN
On
ALARM
Off
2
Not sounding
OPERATION
Flashing
16 - 31
16
15
(= 8 + 4 + 2 + 1)
31
(= 16 + 15)
TIMER
Flashing
DEF./FAN
Flashing
ALARM
Flashing
3
Sounding
OPERATION
On
32 - 47
32
14
(= 8 + 4 + 2)
46
(= 32 + 14)
TIMER
On
DEF./FAN
On
ALARM
Off
4
Sounding
OPERATION
Flashing
48 - 63
48
15
(= 8 + 4 + 2 + 1)
63
(= 48 + 15)
